fish smoking machine, fish smoking and drying machine, meat smoking machine

FOB Reference Price:Get Latest Price
US $6,588-6,599 / Sets | 1 Set/Sets smoke oven (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Sausage
Application:
it's used to smoke meat,fish
Automatic Grade:
Automatic
Production Capacity:
50kg/time
Place of Origin:
Henan, China (Mainland)
Brand Name:
hongxin
Model Number:
JX-50
Voltage:
380V
Power(W):
9200
Dimension(L*W*H):
1200*1000*1680mm
Certification:
CE ISO
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
kw:
smoke oven
model:
JX-50
capacity:
50kg/time
steam pressure:
0.1~0.2 Mpa
furnace temperature:
<100℃
dimension:
1200*1000*1680mm
Supply Ability
Supply Ability:
200 Set/Sets per Month fish smoking machine, meat smoking machine
Packaging & Delivery
Packaging Details
export standard wooden case
Port
Qingdao
Lead Time :
20 working days after receiving clients down payment

fish smoking machine, fish smoking and drying machine, meat smoking machine

Introduction:

1. it is suitable for smoking meat  sausage fish  duck and poultry  aquatic products and other  smoked products

2. Types:electric heating smoke house,baking smoke house,steam smoke house,refrigerating smoke house,heat conduction oil house

3. With low energy consumption,heating up fast , cooking,drying,baking,cold smoked,hot smoked,spray cooling and other functions

4. the key components is the steam pipes,heat exchanger (baking functionality requires installation of electric pipe) and outlet channels . The mixture of hot air and the fume inside become vortext region under the effect of two groups of circle fans ,so that the mixture gas through the meat hanging in the smoke box enevtly in appropriate rate to curing and sterilize

5. All of our machines are produced by good quality stainless steel 304.

And all our machines have three functions: drying, smoking and air cooking.

Specification:

Model

JX-50

JX-100

JX-150

Capacity

50kg /time

100 kg/time

150 kg/time

Total power ( Kw)

9.2 kw

10.5 kw

11.8 kw

Steam pressure

0.1~0.2 Mpa

0.1-0.2 Mpa

0.1-0.2 Mpa

Furnace temperature

<100℃

<120℃

<120℃

Machine size (mm)

1200*1000*1680mm

1700*1050*1978mm

1740*1100*2160mm
